Lamborghini Boathouse Apartment
Drive Through Bay Doors, Mega Electrical Package, 20' Dormers, Framed In Bathroom and Driveway Extensions
With 80’ driveway extension around left side of house, homeowner did not care to back in his boat; therefore, the left bay was a drive thru for dropping the boat trailer. Right side of the garage stored beautiful Lamborghini. Upstairs was a combination of full bath, workout room, computer work station, guest bed/studio apartment.
Lamborghini Boathouse Apartment
Foundation: Footer; approximate brick and block to 12” above slab
Walls/Ceiling Height:
First floor walls 8’ standard to 9’ ceiling
2nd story 1 – 3’ knee-wall full length, 20’ dormer wall standard 8’ to 8’ ceiling
Windows: 5 – 2/8×4/4 double hung vinyl, some tempered glass
Floor: Troweled smoothed finished slab; 2nd story : manufactured/engineered 20” tall floor trusses @ 19-2” OC covered in ¾” T&G Adventec
Doors:
3 – 9Wx8H, wind load to meet code, insulated, windowed, inserts, w/ garage door openers
2 – 3/0x6/8 exterior metal entry 9 lite
Roof: Stick built 2×6 rafters @ 16 OC to ridge beam; OSB roof decking w/ clips, 30 # felt, shingles to match house, Vent-O-Ridge II, drip edge; left side 12/12 pitch, right side 12/12 and 4/12 pitch
Interior: Unfinished
Exterior: Hardiplank lapsiding, Meritech trim, exterior decorative stairs
Options:
Drive thru bay garage doors
Mega electrical package
Garage door openers
20’ dormers
Exterior steps
Water tables
Two coat painted
Driveway extension
Bathroom framed in
Drive Through Bay Doors, Mega Electrical Package, 20' Dormers, Framed In Bathroom and Driveway Extensions
